Specifications OTHER FEATURES: Distributed, masterless system architecture Redundant dual ring fiber optic network Up to 128 network nodes within a single fiber network DSP at every I/O for audio signal processing VOX at every port Hot swap of all modules Redundant power supplies Redundant node controller Ethernet tunneling through Ethernet interface Intuitive configuration software Multiple PCs can configure same system User rights management Optional external sync (AES3/Word Clock) Stand alone version Alarm signalization (Hardware/Director) Max ports per frame: 64 Controller slots per frame: 2 Client slots per frame: 8 GPI card slots per frame: 1 Mainframes: MFR-064 G2 Controller Cards: CPU-128 G2 Fiber optic modules: FOM-SM (single mode) FOM-MM (multi-mode), FOM-MM-HP (high power) Power Supplies: PSE-064 G2 CLIENT CARDS: Digital Client Card Coax: COX-108 G2 8 digital control key-panel ports on individual 75ohm BNC connectors for connection of Artist key panels using coax cable Digital Client Card CAT5: CAT-108 G2 8 digital control key-panel ports on individual RJ-45 connectors for connection of Artist key panels using CAT5 computer cable Analog Client Card: AIO-108 G2 (AIO-109 G2) 8 transformer balanced (AIO-109 G2: electronically balanced) Analog 4-wire intercom ports ( 18dBu in/out) on individual RJ-45/D-Sub25 for connection to equipment such as studio loudspeakers, cameras, telephone hybrids etc. Digital Client Card AES: AES-108 G2 Digital audio I/O-card (4x AES3) incl. Sample Rate Converter on RJ-45 for connection to digital mixing consoles, routers etc. GPI Client Card: GPI-116 G2 16 outputs (300 mA, 60V) and 16 opto-isolated level inputs (5-48V) on SubD37 to read Tallies, key transmitters, etc. 8 Channel MADI Client Card: MADI-108 G2 Cascadable to 64 channels on one MADI stream. Includes audio & panel data to remote panels or connect multi-channel audio to audio routers. Optical & Coax MADI links are supported. 8 Channel VoIP Client Card (EBU Tech 3347 compatible): VOIP-108 G2 Converts 8 Artist control key-panel ports into a compressed IP-stream and vice versa, SIP-based, RJ45 connector 8 Channel Ethernet AVB Client Card (AVnu AVB): AVB-108 G2 Converts 8 Artist control key-panel ports into an Ethernet AVB stream and vice versa, RJ45 connector SIZE: Modular WEIGHT: Modular
