LECTROSONICS UMC16A MULTI-COUPLER

Specifications Type: Active RF distribution system with ceramic filtering Inputs: Two 50 Ohm BNC jack on rear panel Third order intercept: 27dBm at input Outputs: Type: 16 BNC jacks on rear panel. Eight jacks per antenna. Isolation: 25dB min, any output to any output Any output can be open, shorted, or terminated without affecting other outputs. Splitter type: Wilkinson 1/4 wave Frequency Range: 470 to 865MHz, factory set (See serial number sticker on side panel for frequency range of your particular unit.) Filter bandwidth: 16 to 50MHz, factory set Input/Output RF gain 1 to 2dB at center of band Power Requirements: 95-240VAC or 11 to 14VDC Overload protection provided by internal auto-reset circuit breaker. Power consumption: Nominally 110-220VAC, 10 Watts Nominally 340mA at 12VDC SIZE: 19″ x 7″ x 1.75″ 483 x 178 x 45 mm WEIGHT: 2.6 lbs. (1.2 kg)
