ForA HVS 390HS HD/SD 1M/E – 2M/E Video Switcher

Specifications Number of M/Es 1 M/E or 2 M/E Control Panel 4 types HVS-391OU: 1 M/E 20-button model HVS-392WOU: 2 M/E 28-button model HVS-392OU: 2 M/E 20-button model HVS-392ROU: 2 M/E 12-button rack size model Video Formats 1080/59.94i, 1080/50i, 1080/29.97PsF, 1080/25PsF, 1080/24PsF, 1080/23.98PsF, 720/59.94p, 720/50p, 525/60 (NTSC), 625/50 (PAL) Video Input HD-SDI: 1.5 Gbps or SD-SDI: 270 Mbps 75? BNC x 16 * Frame synchronizer on each input Video Input (optional) HVS-30HSDI HD-SDI: 1.5 Gbps or SD-SDI: 270 Mbps 75? BNC × 4 HVS-30HSAI HD analog component, SD analog component, Analog composite HVS-30PCIN DVI-D: XGA to WUXGA (1080i), XGA to WXGA (720p), VGA to XGA (SD) (HDCP incompatible) RGB: XGA to WUXGA (1080i), XGA to WXGA (720p), VGA to XGA (SD) Number of Inputs Standard: 16 (SDI), Max.: 24 (with HSDI x 2 or HSDI-A x 2) Video Output HD-SDI: 1.5 Gbps or SD-SDI: 270 Mbps 75? BNC x 8 (PGM x 2, AUX x 6), HDMI (AUX) x 1 (HDCP, AUDIO incompatible) Video Output (optional) HVS-30HSDO HD-SDI: 1.5 Gbps or SD-SDI: 270 Mbps 75? BNC x 3 HVS-30HSAO HD analog component, SD analog component, Analog composite HVS-30PCO DVI-D: SXGA to WUXGA/HDTV (1080i), SXGA/WXGA (720p), SVGA (SD) (HDCP incompatible) RGB: SXGA to WUXGA (1080i), SXGA/WXGA (720p), SVGA (SD), YPbPr: HDTV(1080i) Number of Outputs Standard: 9 (SDI x 8, HDMI x 1), Max.: 13 (with 2 output cards) AUX Outputs Standard: 6, Max.: 8 * Crossfade switching available on each AUX output Signal Processing 4:2:2 Digital component Quantization HD/SD-SDI: 10-bit Genlock Input BB: NTSC 0.429 Vp-p / PAL 0.45 Vp-p or Tri-level Sync: 0.6 Vp-p, 75? BNC x 1, loop-through (Terminate with 75? terminator, if unused.) System Phase Adjust Horizontal: -1/2H to 1/2H Genlock Output BB: NTSC 0.429 Vp-p / PAL 0.45 Vp-p or Tri-level Sync: 0.6 Vp-p, 75? BNC x 1 I/O Delay HD: 1 H, SD: 1.7 H (minimum delay) 1 to 2 frames minimum delay (when FS or up-resize engine used) 2 to 3 frames minimum delay (when FS or up-resize engine plus DVE used) 3 to 4 frames minimum delay (when FS or up-resize engine plus output resize engine and DVE used) Interfaces EDITOR: 9-pin D-sub (female) x 1 (inch screw) RS-422: 9-pin D-sub (female) x 6 (inch screw) GPI IN: 15-pin D-sub (female) x 1 (inch screw) 10 inputs TALLY OUT: 25-pin D-sub (female) x 1 (inch screw) 20 outputs ARCNET: 75? BNC x 1, loop-through (Terminate with 75? terminator, if unused.) Ethernet: 100BASE-TX/1000BASE-T RJ-45 x 1 Temperature / Humidity 0°C to 40°C / 30% to 90% (no condensation) Power 100 V AC to 240 V AC ±10%, 50/60 Hz Consumption HVS-390HS: 510 W (at 100-120 VAC) 460 W (at 220-240 VAC) HVS-391OU: 32 W (at 100-120 VAC) 30 W (at 220-240 VAC) HVS-392WOU: 39 W (at 100-120 VAC) 37 W (at 220-240 VAC) HVS-392OU: 43 W (at 100-120 VAC) 40 W (at 220-240 VAC) HVS-392ROU: 28 W (at 100-120 VAC) 26 W (at 220-240 VAC) Dimensions/Weight HVS-390HS: 430 (W) x 450 (D) x 132 (H) mm / Approx. 17 kg (standard), 20 kg (full option) HVS-391OU: 576 (W) x 279 (D) x 131 (H) mm / Approx. 5.5 kg HVS-392WOU: 800 (W) x 409 (D) x 132.6 (H) mm / Approx. 10.5 kg HVS-392OU: 576 (W) x 409 (D) x 132 (H) mm / Approx. 8.5 kg HVS-392ROU: 430 (W) x 409 (D) x 132 (H) mm / Approx. 7.5 kg Accessories Main unit: Operation manual, AC cord, Rack mount brackets (for main unit) HVS-391OU/392WOU/392OU/392ROU: Operation manual, AC cord, BNC cable (10 m) Consumables (if used 24 hours a day at room temperature) Cooling fan: Replace every 4 years Power unit: Replace every 5 years Battery: Replace every 5 years Options Model Name Features HVS-39EXTME M/E expansion card (for 1 M/E model) HVS-30HSDI HD/SD-SDI input card (w/ up-resize engine) HVS-30HSAI Analog input card HVS-30HSAI Analog input card HVS-30HSDO HD/SD-SDI output card HVS-30PCO PC output card HVS-AUX8RK/AUXRK AUX remote extension kit HVS-TALOC20/32 Tally open collector unit (20/32 terminal) HVS-39ED Editor interface software HVS-39PSM Redundant power supply unit for main unit HVS-39MEM Video memory expansion card HVS-30PCIN PC input card HVS-30HSAO Analog output card HVS-AUX8/16/32 AUX remote unit HVS-AUX16A/32A/64A AUX remote unit (Ethernet) HVS-AUX16B AUX remote unit (Ethernet, Desktop Type) HVS-TALR20/32 Tally relay unit (20/32 terminal) HVS-30TALR Tally relay output card HVS-39VR Virtual link software HVS-39PSO Redundant power supply unit for HVS-391OU/392WOU/392OU/392ROU
