Specifications Up to 68 channels of input with optional cards*1 Combine optional input cards, MV-4200SDI (3G/HD/SD-SDI, Composite x20), MV-4200PCI (DVI-I/HDMI/RGBHV x8), or the MV-4200IF interface card (GPIO, serial control, input of analog audio, AES audio, genlock), as needed. 1 Three MV-4200SDI cards. MV-4210 SDI output model Up to 8 channels of SDI video output View up to 8 monitors with different layouts Up to 114 windows over 8 output displays Up to 8 clocks per 8 output displays Up to 8 logos and 1 background per 8 output displays 3G SDI Inpuuts Support 4K (UHD) Source Input Layout Manager enables easy layout of 4K video in a seamless display HDMI 2.0b output 4K (UHD) output (3840 x 2160, YUV 4:2:0) over a single HDMI cable Crosspoint control for 4K playback Four input signals assigned to crosspoints 1 to 4 can be controlled together. 2K or 4K SDI/HDMI output in customizable layouts Mixed 2K/4K output also supported Logo display in title areas Register a logo for each input, or use the same logo for all windows. Up to 8 logos can be registered Import bitmaps from the logo registration screen Titles can also show text entered from a web browser HD to 4K up-resizing Layout Manager Windows-based screen layout creation and management software. Customize layouts using the software to adjust image size, position, title display and other settings. Store up to 68 layout patterns on the multi viewer. Saved layouts can be recalled directly from the front panel control.
